WXF Parallel Shaft Helical Gear Motor

Overview
Technical Information
  • Wide power range: 0.12-200kW
  • Sufficient power, high efficiency and low noise
  • Wide application, easy operation and flexible installation
  • High performance, high load resistance
Power 0.12-200kW
Voltage Single phase 110V/220V, 3 phase 220V/380V/415V/440V/660V/690V (Customizable)
Frequency 50/60Hz
Efficiency IE2，IE3，IE4，IE5
Insulation level F (155℃)
Protection grade IP55
Lubrication Synthetic oil, mineral oil
Gearbox size 37,47,57,67,77,87,97,107,127,157
Features
Parameters
Directory
Features
  • Strong Versatility
    Wide range of ratio and power
  • 20CrMnTi Gear+Carburizing
    Strong carrying capacity, low noise and long service life
  • HT200/HT250 Gearbox
    Good rigidity and high compressive strength
  • Synthetic Oil
    High/low temperature resistance, long service life






WXF Common Models

F...

Foot mounted

FA...B

Foot mounted with hollow shaft

FH...B

Foot mounted with hollow shaft and shrink disk

FV...B

Foot mounted with splined hollow shaft

FF...

B5 flange mounted

FAF...

B5 flange mounted with hollow shaft

FHF...

B5 flange mounted with hollow shaft and shrink disk

FVF...

B5 flange mounted with splined hollow shaft

FA...

Hollow shaft mounted

FH...

Hollow shaft with shrink disk

FV...

Splined hollow shaft mounted

FAZ...

B14 flange mounted with hollow shaft

FHZ...

B14 flange mounted with hollow shaft shrink disk

FVZ...

B14 flange mounted with splined hollow shaft

F...AD

Solid shaft input

F...AM

IEC/AM flange input




Prouduct Advantage


1. Both motor and gearbox are produced by ourselves. Motor power is sufficient, with low temperature rise.
2. Short lead time.
3. Fully equipped with motors, connecting flanges, torque arms, shrink disks, and various types of combination options.
4. 20CrMnTi gear with carburizing technology, effectively improves the bearing capacity of the gear. Gears and gear shafts adopt grinding and cultivation technology, lowering gear operating noise.
5. The output shaft adopts 40Cr+quenching and tempering high-frequency treatment, and the oil seal position adopts radial grinding to improve wear resistance and reduce the risk of oil leakage.
