WXS Helical Worm Gear Motor

Overview
Technical Information
  • Wide power range: 0.12-22kW
  • Sufficient power, high efficiency and low noise
  • Wide application, easy operation and flexible installation
  • High performance, high load resistance
Power 0.12-22KW
Voltage Single phase 110V/220V, 3 phase 220V/380V/415V/440V/660V/690V (Customizable)
Frequency 50/60Hz
Efficiency IE2，IE3，IE4，IE5
Insulation level F (155℃)
Protection grade IP55
Lubrication Synthetic oil, mineral oil
Gearbox size 37,47,57,67,77,87,97
Features
Parameters
Directory
產品特點
  • Strong Versatility
    Wide range of ratio and power
  • Tin Bronze Gear
    Strong carrying capacity, low noise and long service life
  • HT200/HT250 Gearbox
    Good rigidity and high compressive strength
  • Synthetic Oil
    High/low temperature resistance, long service life






WXS Common Models

S... Foot-mounted
SF... B5 flange mounted
SAF... B5 flange mounted with hollow shaft
SHF.. . B5 flange mounted with hollow shaft and shrink disk
SA... Hollow shaft mounted
SH... Hollow shaft with shrink disk
SAZ... B14 flange mounted with hollow shaft
SHZ... B14 flange mounted with hollow shaft and shrink disk
S...AD Solid shaft input
S...AM IEC/AM flange input




Prouduct Advantage


1. Both motor and gearbox are produced by ourselves. Motor power is sufficient, with low temperature rise.
2. Short lead time.
3. Fully equipped with motors, connecting flanges, torque arms, shrink disks, and various types of combination options.
4. 20CrMnTi gear with carburizing technology, effectively improves the bearing capacity of the gear. Gears and gear shafts adopt grinding and cultivation technology, lowering gear operating noise.
5. The output shaft adopts 40Cr+quenching and tempering high-frequency treatment, and the oil seal position adopts radial grinding to improve wear resistance and reduce the risk of oil leakage.
